9 way r/angle PCB D plug
Roll over or select images to enlarge

D Connectors - Right Angle PCB

Brand
Scroll Down for Pricing Options

Superior quality commercial right angle PCB mounting sub-D connectors. Manufactured to MIL-C-24308 dimensional specifications. All types have tin plated shells, with grounding fingers on plug shells to ensure full EMI/RFI shielding. Jack posts and PCB locating lugs are incorporated. Standard 7.2mm (U.S.) footprint.

RoHS compliant

Insulator material:Glass filled polyester
Contact material:Phosphor bronze, gold plate over nickel
Contact rating:5 A
Dielectric strength:1000 VAC
Insulation resistance:1000MΩ minimum at 500 VDC
Contact resistance:30mΩmax. at 100VDC
Temperature range:-55°C to +105°C

View product specifications
Pricing Options
Have a question? Call us on +44 (0) 1582 47 00 00
Add to basket

Product Specifications

Specification 720-055 720-060 720-065 720-070 720-075 720-080 720-082
Type
9 way R/A PCB plug - Pinrex 982-11-A09112 9 way R/A PCB socket - Pinrex 982-11-B09112 15 way R/A PCB plug - Pinrex 982-11-A15112 15 way R/A PCB socket - Pinrex 982-11-B15111 25 way R/A PCB plug - Pinrex 982-11-A25111 25 way R/A PCB socket- Pinrex 982-11-B2511112 37 way R/A PCB plug - Pinrex 982-11-A37112
