Hammond 1455NC Series Aluminium Channel Mount
Hammond 1455NC series extruded aluminium enclosures are designed to be easily mounted onto equipment or machinery via T bolt and channel.
Accessory packs of nuts, bolts and nuts & springs also available.
Designed to house P.C. boards or equipment - for easy enclosure mounting to aluminum channel.
View product specifications
Accessory packs of nuts, bolts and nuts & springs also available.
Designed to house P.C. boards or equipment - for easy enclosure mounting to aluminum channel.
- Two versions to choose from (open bezel with metal endplates OR solid ABS plastic bezel).
- Both types are available in three sizes.
- Sized for P.C. boards with 92mm (min.) to 98mm (max.) width.
- P.C. boards mount horizontally by sliding into internal slots extruded into the enclosure body.
- Rugged one piece body - constructed from extruded aluminum with a minimum thickness of .09” (2.29 mm).
- Extruded body & aluminum endplates (on metal endplate version) are clear anodized.
- Open bezel - metal endplate version includes eight (8) clear zinc plated assembly screws.
- Solid bezel version includes eight (8) black assembly screws.
- NOTE: Recommended screw torque is 5lbf/in.
- STANDARD LEAD TIME 5-7 DAYS
Pricing Options
Have a question? Call us on +44 (0) 1582 47 00 00
Details
Order Code
Description
Price Each Exc VAT (Inc VAT)
1+
10+
25+
Add to basket
Request Lead Time
Order Code:
Description:
1455NC1201 Aluminium Enclosure 120x103x53 Metal ends
1455NC1201 Aluminium Enclosure 120x103x53 Metal ends
£18.179
(£21.815)
£16.567
(£19.880)
£15.288
(£18.346)
Price Each Exc VAT (Inc VAT)
Stock Qty: 0
1+ @ £18.179
(£21.815)
10+ @ £16.567
(£19.880)
25+ @ £15.288
(£18.346)
hide price breaks
view price breaks
Stock Qty: 0
Order Code:
Description:
1455NC1202 Aluminium Enclosure 120x103x53 ABS ends
1455NC1202 Aluminium Enclosure 120x103x53 ABS ends
£15.766
(£18.919)
£14.383
(£17.260)
£13.270
(£15.924)
Price Each Exc VAT (Inc VAT)
Stock Qty: 0
1+ @ £15.766
(£18.919)
10+ @ £14.383
(£17.260)
25+ @ £13.270
(£15.924)
hide price breaks
view price breaks
Stock Qty: 0
Order Code:
Description:
1455NC1601 Aluminium Enclosure 160x103x53 Metal ends
1455NC1601 Aluminium Enclosure 160x103x53 Metal ends
£20.436
(£24.523)
£18.637
(£22.364)
£17.191
(£20.629)
Price Each Exc VAT (Inc VAT)
Stock Qty: 0
1+ @ £20.436
(£24.523)
10+ @ £18.637
(£22.364)
25+ @ £17.191
(£20.629)
hide price breaks
view price breaks
Stock Qty: 0
Order Code:
Description:
1455NC1602 Aluminium Enclosure160x103x53 ABS ends
1455NC1602 Aluminium Enclosure160x103x53 ABS ends
£17.961
(£21.553)
£16.380
(£19.656)
£15.111
(£18.133)
Price Each Exc VAT (Inc VAT)
Stock Qty: 0
1+ @ £17.961
(£21.553)
10+ @ £16.380
(£19.656)
25+ @ £15.111
(£18.133)
hide price breaks
view price breaks
Stock Qty: 0
Order Code:
Description:
1455NC2201 Aluminium Enclosure 220x103x53 Metal ends
1455NC2201 Aluminium Enclosure 220x103x53 Metal ends
£23.899
(£28.679)
£21.798
(£26.158)
£20.103
(£24.124)
Price Each Exc VAT (Inc VAT)
Stock Qty: 0
1+ @ £23.899
(£28.679)
10+ @ £21.798
(£26.158)
25+ @ £20.103
(£24.124)
hide price breaks
view price breaks
Stock Qty: 0
Order Code:
Description:
1455NC2202 Aluminium Enclosure 220x103x53 ABS ends
1455NC2202 Aluminium Enclosure 220x103x53 ABS ends
£21.497
(£25.796)
£19.604
(£23.525)
£18.086
(£21.703)
Price Each Exc VAT (Inc VAT)
Stock Qty: 0
1+ @ £21.497
(£25.796)
10+ @ £19.604
(£23.525)
25+ @ £18.086
(£21.703)
hide price breaks
view price breaks
Stock Qty: 0
Order Code:
Description:
1455TBOLT Set of Two for 1455NC8x20mm T bolts, washers & hex nuts
1455TBOLT Set of Two for 1455NC8x20mm T bolts, washers & hex nuts
£5.106
(£6.127)
£4.659
(£5.591)
£4.295
(£5.154)
Price Each Exc VAT (Inc VAT)
Stock Qty: 0
1+ @ £5.106
(£6.127)
10+ @ £4.659
(£5.591)
25+ @ £4.295
(£5.154)
hide price breaks
view price breaks
Stock Qty: 0
Order Code:
Description:
1455TNUT Set of two for 1455NC 8mm T nuts
1455TNUT Set of two for 1455NC 8mm T nuts
£4.794
(£5.753)
£4.368
(£5.242)
£4.035
(£4.842)
Price Each Exc VAT (Inc VAT)
Stock Qty: 0
1+ @ £4.794
(£5.753)
10+ @ £4.368
(£5.242)
25+ @ £4.035
(£4.842)
hide price breaks
view price breaks
Stock Qty: 0
Order Code:
Description:
1455TSNUT Set of two for 1455NC 8mm T nuts & springs
1455TSNUT Set of two for 1455NC 8mm T nuts & springs
£6.344
(£7.613)
£5.782
(£6.938)
£5.335
(£6.402)
Price Each Exc VAT (Inc VAT)
Stock Qty: 0
1+ @ £6.344
(£7.613)
10+ @ £5.782
(£6.938)
25+ @ £5.335
(£6.402)
hide price breaks
view price breaks
Stock Qty: 0
Product Specifications
| Specification | 880-611 | 880-612 | 880-613 | 880-614 | 880-615 | 880-616 | 880-617 | 880-618 | 880-619 |
|---|---|---|---|---|---|---|---|---|---|
|
Dimensions (LxWxH)
|
120x103x53 - Metal end plates (1455NC1201) | 120x103x53 - ABS end plates (1455NC1202) | 160x103x53 - Metal end plates (1455NC1601) | 160x103x53 - ABSl end plates (1455NC1602) | 220x103x53 - Metal end plates (1455NC2201) | 220x103x53 - ABS end plates (1455NC2202) | 8x20 bolt, washer + hexnut (x2 ea) 1455TBOLT | 8mm T nuts (x2 ea) 1455TNUT | 8mm T nuts & springs (x2 ea) 1455TSNUT |
