Hongfa Slimline 24V Power Relay HF49FA
Miniature PCB power relay, single pole normally open contact arrangement. IP67 sealed.
2kV coil-contact isolation. UL & TUV approved.
RoHS compliant
| Contact form: | 1A (SPNO) |
| Contact rating: | 5A 250VAC/30VDC |
| Contact material: | AgSnO2 |
| Operate/release: | 10ms/5ms |
| Coil consumption: | 120mW |
| Mechanical life: | 2x107 operations |
| Temperature range: | -40°C to +85°C |
| Dimensions: | 20L x 5.0W x 12.5H |
**** Available until stocks exhausted ****
Pricing Options
Have a question? Call us on +44 (0) 1582 47 00 00
Product Specifications
| Specification | 820-091 |
|---|---|
|
Max. Switching Capacity
|
150W/1250VA |
|
Coil Voltage
|
5VDC |
|
Coil Resistance
|
208 ohms |
