Hongfa Miniature BT47 Relays HFD27 - DPCO 1A
by Hongfa
Miniature double pole changeover relay for DIL or direct PCB mounting. Fluxproof, fully sealed construction. Suitable for telecoms, computer circuits, alarms etc. IP67 sealed.
UL/CUL TÜV CQC approved
RoHS compliant
Equivalent to the following;
OMRON : G5V-2
PANASONIC : DS2Y
FUJITSU FBR244/FTR-C2/RY
NEC MR62
AXICOM V23105/D2N
| Contact form: | 2CO (DPDT) |
| Contact rating: | 1A 125VAC/2A 30VDC |
| Contact material: | AgNi+Au plated |
| Operate/release: | 6ms/4ms |
| Coil consumption: | 280-580mW |
| Mechanical life: | 1x105 operations |
| Temperature range: | -40°C to +85°C |
| Dimensions: | 20.2L x 11.5H x 10W |
Pricing Options
Have a question? Call us on +44 (0) 1582 47 00 00
Product Specifications
| Specification | 821-317 | 821-320 |
|---|---|---|
|
Max. Switching Capacity
|
125VA/60W | 125VA/60W |
|
Coil Resistance
|
450 ohms | 1600 ohms |
|
Coil Voltage
|
12VDC | 24VDC |
