Finder 41.31 Relays - SPCO 12A
by Finder
Low-profile miniature power relay with 6kV-8mm coil contact isolation. Pin spacing 3.5mm. Flux-tight base with pre-tinned terminals. Protection category IP50. UL, CSA, VDE approved.
| Contact form: | 1C (SPDT) |
| Contact rating: | 12A 250VAC/30VDC |
| Contact material: | AgNi |
| Operate/release: | 7ms/8ms |
| Temperature range: | -40°C to +85°C |
| Dimensions: | 29L x 15.7H x 12.7W |
Pricing Options
Have a question? Call us on +44 (0) 1582 47 00 00
Product Specifications
| Specification | 820-155 | 820-157 |
|---|---|---|
|
Finder Part no.
|
41.31.9012.0010 | 41.31.9024.0010 |
|
Switching capacity
|
3000VA | 3000VA |
|
Coil resistance
|
360Ω | 1440Ω |
|
Coil Voltage
|
12VDC | 24VDC |
