High Power Infrared Source and Sensor

Scroll Down for Pricing Options

Spectrally matched near infra-red source and sensor comprising a high output infra-red emitter in standard 5 mm LED package (TSUS5400) and a high speed silicon PIN photodiode sensor, housed in an infra-red transmissive moulding ( BPW41). Designed for high speed photo-detector use, remote control circuits etc. Full data sheet available on request.

Emitter
Forward voltage max:1.7V
Forward current max:150mA
Radiant power @ 100mA:15mW typ.
Peak wavelength @ 100mA:950nm
Sensor
Breakdown voltage (Ir=100mA):32V min.
Dark current (Vr=10V):2nA typ.
Light current (Vr=5V):45µA typ.

RoHS compliant

View product specifications
Pricing Options
Have a question? Call us on +44 (0) 1582 47 00 00
Description
Add to basket
Price Each Exc VAT (Inc VAT)
Price Each Exc VAT (Inc VAT)

Product Specifications

Specification 850-330 850-335
Description
High power I.R. emitter TSUS5400 High power I.R. sensor BPW41N
