Roll over or select images to enlarge
2.2uF 35V Tant. Bead Capacitor5mm Pitch
by Hitano
Low cost, small size. Suitable for industrial and consumer applications
where high performance and stability are required.
| Temp. range: | -55°C to +125°C |
| Tolerance: | ±20% |
| Leakage current: | <0.01CV or 0.5µA @20°C (whichever greater) |
| Lead pitch: | 5 mm |
RoHS compliant
Pricing Options
Have a question? Call us on +44 (0) 1582 47 00 00
Product Specifications
| Specification | 150-035 |
|---|---|
|
Voltage (VDC)
|
35 |
|
Value
|
2.2µF |
|
LxDia. (max)
|
10.0x5.0 |
