WAGO 855-8003 Power tap; with fuse; 10mm² -16mm²
by Wago
WAGO 855-8003
- Power tap
- with fuse
- 10 mm² (8 AWG) - 16 mm² (6 AWG)
- Phase
WAGO's voltage taps (855 Series) easily and safely tap the measurement voltage.
This allows a fuse-protected measurement voltage to be tapped from an insulated conductor with just one turn – no tools required.Features:
- Safely tap the measurement voltage with just one turn
- Tool-free assembly
- Secure mounting
- Voltage taps (855-8001 and 855-8003) include a (5 x 25) mm 2A fuse
- For insulated conductors up to 16 mm² (6 AWG)
- Cable length: 3 m
Spare fuse: WAGO 855-8020
Pricing Options
Have a question? Call us on +44 (0) 1582 47 00 00
Product Specifications
| Specification | 855-8003 |
|---|---|
|
Connection technology:
|
IDC connection |
|
Continuous current (max.)
|
2A |
