50W IDC header plug r/angle
by Pinrex
PCB mounting plugs for direct soldering to a printed circuit board. Mounting holes are provided at each end of the connector. Available in straight or right angle form, these plugs mate directly with IDC type cable sockets.
All types have long securing latches to take cable sockets complete with strain relief clips.
The clips act also as an ejector when disengaging the sockets from the plugs.
Pinrex 51F-70-XXXX51
RoHS compliant
| Terminal pitch: | 0.1" 2.54mm |
| Insulator material: | PBT |
| GV to UL94V0 | |
| Contacts: | Brass - gold flashed |
| Temp range: | -65°C to +125°C |
| Working Voltage: | 250V AC |
| Current rating: | 1 A |
| Test voltage: | 1,000 V |
Pricing Options
Have a question? Call us on +44 (0) 1582 47 00 00
Product Specifications
| Specification | 730-075 |
|---|---|
|
Fixing Centres
|
79.0mm |
|
Description
|
50 way 90° plug 51G-70-50GB51 |
|
Overall Length
|
82.9mm |
