Pinrex 982-31 Series D Connectors - Panel Mounting

Brand
Scroll Down for Pricing Options
9 way D plug
Roll over or select images to enlarge

Pinrex 982-31 Series D Connectors - Panel Mounting

Brand
Scroll Down for Pricing Options

Superior quality commercial sub-miniature D connectors in 9 to 37 way contact versions,
with solder bucket terminals.
Flame retardant polyester insulator material.
Gold plated brass contact elements. Manufactured to MIL-C-24308 dimensional specification.

Tin plated dimpled steel shells ensure full grounding for EMI/RFI shielding.

Contact rating:1 A
Dielectric strength:500 VAC
Insulation resistance:1000MΩ minimum at 500 VDC
Contact resistance:30mΩ max. at 100VDC
Temperature range:-40°C to +105°C

RoHS compliant

View product specifications
Pricing Options
Have a question? Call us on +44 (0) 1582 47 00 00
Add to basket

Product Specifications

Specification 720-005 720-010 720-015 720-020 720-025 720-030 720-035 720-040
Type
9 way solder plug- Pinrex 982-31-A09203 9 way solder socket Pinrex 982-31-B09203 15 way solder plug - Pinrex 982-31-A15203 15 way solder socket - Pinrex 982-31-B15203 25 way solder plug - Pinrex 982-31-A25203 25 way solder socket - Pinrex 982-31-B25203 37 way solder plug - Pinrex 982-31-A37203 37 way solder socket - Pinrex 982-31-B37203
